Communication and Positioning
|
|
GSM |
4G (LTE Cat 1/4/M1/NB2), 3G, 2G
|
|
GNSS antenna |
Built-in antenna
|
|
Bluetooth |
Support Bluetooth 4.2 and Bluetooth 5.0
|
|
Positioning accuracy |
2.5m
|
Power
|
|
Power supply |
DC 11.4–90 V/1.5 A
|
|
Backup battery |
Internal 400 mAh battery (normal temperature resistant: -20°C to 60°C)
|
|
Power consumption |
Current in standby mode: 65 mA
|
Physical Specifications
|
|
Dimensions |
80.5 mm x 60 mm x 23.5 mm
|
|
Weight |
100g
|
Operating Environment
|
|
Operating temperature |
-35°C to 80°C (available for the device without a battery) -5°C to 75°C (available for the device with a high temperature resistant battery)
|
|
Operating humidity |
5% to 95%
|
|
Ingress protection |
IP67
|
Functions
|
|
Memory |
8 MB buffer
|
Frequency Bands
|
|
Global |
T399E-GFB5 LTE CAT M1/NB: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26(CAT M1)/B27（CAT M1）/B28/B66/B71(NB)/B85 GSM:850/900/1800/1900MHz T399L-GFB5: LTE CAT1 FDD:B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/B19/B20/B25/B26/B28 TDD:B38/B39/B40/B41 WCDMA:B1/B2/B4/B5/B6/B8/B19 GSM:850/900/1800/1900MHz
|
|
Africa/Europe/Middle East |
T399L-EA: FDD: B1/B3/B7/B8/B20/B28, TDD: B38/B40, WCDMA: B1/B8, GSM: 900/1800MHz T399L-ER: FDD: B1/B3/B5/B7/B8/B20/B28, TDD: B38/B40/B41 GSM: B2/B3/B5/B8
|
|
Americas |
T399L-AFB5: LTE CAT1:B2/B4/B12 WCDMA:B2/B4/B5
|
|
Australia |
T399L-AUFB5: LTE CAT1 FDD:B1/B2/B3/B4/B5/B7/B8/B28 TDD:B40 WCDMA:B1/B2/B5/B8 GSM: 850/900/1800/1900MHz T399L-AUR GSM:B2/B3/B5/B8 LTE-FDD:B1/B2/B3/B4/B5/B7/B8/B28/B66 LTE-TDD:B38/B40/B41
|
|
Japan |
T399L-JFB5: LTE CAT1 FDD::B1/B3/ B8/B18/ B19/B26
|
Others
|
|
OTA/FOTA |
FOTA (T399L)
|
|
Certification |
CE, CITC
|
Supported Peripherals
|
|
RFID |
√
|
|
iButton |
√
|
|
Relay (12 V/24 V) |
√
|
|
Buzzer |
√
|
|
BLE temperature & humidity sensor |
√
|
|
Ultrasonic fuel level sensor |
√
|
|
Fuel level sensor |
√
|
|
Digital temperature sensor |
√
|
|
Battery |
√
|
